9 Module, 46.08kWh, HOME-ESS-HV-5.12K

Versandkosten inkl.

Allgemeine Informationen

Gewicht (Kg): 406

Nennenergie (kWh): 46.08

Modul Gewicht: 43Kg

Garantie: 10 Jahre

Dimension(W*D*H) (mm): 650*355*1910

Spezifikationen

Cell Type: LFP(LiFePO4) Module Energy: 5.12kWh Module Weight: 43Kg

Number of Modules: 9

Nominal Energy (kWh): 46.08

Nominal Voltage (V): 460.8

Operating Voltage Range (V): 432-518.4

Dimension(W*D*H) (mm): 650*355*1910

Weight (Kg): 406

Charging Temperature: From -5 to 55°C Discharging Temperature: From -20 to 55°C Depth of Discharge: 95% DOD Nominal Charge/Discharge Current: 50A Max. Charge/Discharge Current: 100A Cycle Life: >6000, 25°C Ingress Protection Degree: IP65 Cooling Type: Natural convection Humidity: 5%~95% Altitude: <2000 Warranty: 10 years Communication: CAN/RS485/WIFI/Bluetooth Battery Safety: IEC 62619/IEC 62477/CE Transportation Certification: UN38.3
